Cable type 1 Standard T-568B (of TRON 40 VDR MKI)
Serial numbers docking module 0-7500 (summer 2014 - 2016)
VDR-side
Connector
pin
TRON 40VDR side
Rx+
White/Orange
1
White/Orange
Rx+
Rx-
Orange
2
Orange
Rx-
Tx+
White/green
3
White/green
Tx+
Tx-
Green
4
Green
Tx-
N/A
NOT connected
5
White/blue
Connected but not used
DC+
White/blue + Blue
6
Blue
DC+
DC-
White/brown + Brown
7
White/brown
DC-
N/A
Not connected
8
Brown
Connected but not used
Cable type 1 Standard T-568B (of TRON 40 VDR MKII)
Serial numbers docking module > 11203 (from October 2017)
VDR-side
Connector
pin
TRON 40VDR side
Rx+
White/orange
1
White/orange
Rx+
Rx-
Orange
2
Orange
Rx-
Tx+
White/green
3
White/green
Tx+
Tx-
Green
4
Green
Tx-
N/A
Not connected
5
White/blue
Connected but not used
DC+
White/blue + Blue
6
White/brown
DC+
DC-
White/brown + Brown
7
Blue
DC-
N/A
Not connected
8
Brown
Connected but not used
Cable type 2 Proprietary (of TRON 40 VDR MKII)
Serial numbers docking module 7500-12000 (summer 2016 - October 2017)
VDR-side
Connector
pin
TRON 40VDR side
Rx+
White/orange
1
Black
Rx+
Rx-
Orange
2
Brown
Rx-
Tx+
White/green
3
Green
Tx+
DC+
White/blue + Blue
4
Orange
DC+
N/A
Unconnected
5
White
Connected but not used
Tx-
Green
6
Yellow
Tx/ DC-
DC-
White/brown + Brown
7
Blue
DC-
N/A
Unconnected
8
Red
Connected but not used
