13 DISMANTLING AND ASSEMBLY
OF SPECIAL UNITS
PAGE
13.7R
■ Screw the nut (4465) with reducing fitting (4540) on to the sensor conduit (4570) and
tighten down against the stator (3005).
■ Apply some heat transfer paste to the sensor conduit (4570).
■ Mounting snap elbow (4710):
■ Where a snap elbow (4710) is folded down, please unfold by simultaneously
undoing both hooks at (A) with the help of two screw drivers.
■ Screw the snap elbow (4710) into the reducing fitting (4540) and loosen the
screwed cable gland.
■ Insert the temperature sensor (4180) through the screwed cable gland down to the
bottom into the sensor conduit (4570).
■ Tighten the screwed cable gland while the cable is straight so that the cable is
fixed in the seal rubber.
■ Snap the elbow part (4710) shut with hooks (A) closed on both sides.
▲ The temperature controller can be installed in a switchboard.
For installation dimensions pl. see Technical Data in section 2.
text no.
R 13105-3/8
issued: 14.10.2019
Revision: 23
copy to:
88
