NISE 104 User Manual
Chapter 1: Product Introduction
Hardware Specifications
CPU Support
▪ On-board Intel® Atom™ Dual Core processor D2550, 1.86 GHz, 1M L2
cache
▪ Intel® NM10 Express chipset
Main Memory
▪ 1x DDR3 SO-DIMM sockets, support up to 4G DDR3-800/1066 SDRAM,
un-buffered and non-ECC
I/O Interface-Front
▪ ATX power on/off switch
▪ HDD access/power status LEDs
▪ 4x COM ports (COM2 & 3: RS232/422/485)
▪ 2x USB2.0 port
▪ Audio jack (speaker-out & mic-in)
▪ 2x antenna holes
I/O Interface-Rear
▪ 2x Intel® 82574L GbE LAN port
▪ 4x USB2.0 port
▪ 1x HDMI
▪ 1x DVI-I (support VGA & DVI-D display via cable)
▪ 1x 2-pin DC input, Support 9-36V DC input
▪ 1x external screwed type CFast socket
Device
▪ 1x 2.5” HDD drive bay
▪ 1x External CFast Socket
▪ 1x mini-PCIe socket (support optional Wi-Fi or 3.5G module)
Power Requirements
▪ Support 10-28V DC input
▪ 1x optional 12V, 60W power adapter
Dimensions
▪ 185mm(W) x 131mm(D) x 54mm(H) (7.28”x 5.2”x 2.13”)
Construction
▪ Aluminum chassis with fanless design
Environment
▪ Operating temperature: Ambient with air flow: -5°C ~ 55°C (according
to IEC60068-2-1, IEC60068-2-2, IEC60068-2-14)
▪ Storage temperature: -20°C ~ 80°C
▪ Relative humidity: 10% to 93% (non-Condensing)
▪ Shock protection: 20G, half sine, 11ms, IEC60068-2-27
▪ Vibration protection
Random: 0.5Grms @5~500 Hz according to IEC68-2-64
Sinusoidal: 0.5Grms @5~500 Hz according to IEC68-2-6
Certifications
▪ CE approval
▪ FCC Class A
