NISE 104 User Manual
Chapter 2: Jumpers and Connectors
Line-out Pin Header
Connector type: 3.5mm TRS
Connector location: SPK1
NISKIO2
B to B Connector
Connector type: 2x10 20-pin header
Connector location: JP1
12
1920
Pin Definition Pin Definition
1 VCC5 2 VCC5
3 I_USBN4 4 I_USBN5
5 I_USBP4 6 I_USBP5
7 GND 8 GND
9 VCC3 10 I_USBOC#45
11 POWER_LED_PWR 12 HDD_LED_PWR
13 PWR_LED_N 14 HDD_LED_N
15 CODEC_HDASDO 16 CODEC_HDASYNC
17 CODEC_HDABCLK 18 CODEC_HDARST#
19 I_HDASDI0 20 I_SPKR
Pin Definition
1 GND
2 OUT_L
3 EXLINEOUT_JD
4 NC
5 OUT_R
