NISE 104 User Manual
Chapter 2: Jumpers and Connectors
Mini-PCIe Slot
Connector location: CN8
1 2
51 52
Pin Definition Pin Definition
1 PCIEWAKE# 2 +3VSB
3 NC 4 GND
5 NC 6 +1.5V
7 CLKREQ# 8 NC
9 GND 10 NC
11 REF CLK- 12 NC
13 REF CLK+ 14 NC
15 GND 16 NC
17 NC 18 GND
19 NC 20 Disable#
21 GND 22 RST#
23 PCIERX0- 24 +3VSB
25 PCIERX0+ 26 GND
Pin Definition Pin Definition
27 GND 28 +1.5V
29 GND 30 SMBCLK
31 PCIETX0- 32 SMBDATA
33 PCIETX0+ 34 GND
35 GND 36 USB_D-
37 GND 38 USB_D+
39 +3VSB 40 GND
41 +3VSB 42 NC
43 GND 44 NC
45 NC 46 NC
47 NC 48 +1.5V
49 NC 50 GND
51 NC 52 +3VSB
