NISE 104 User Manual
Chapter 2: Jumpers and Connectors
Line-out Internal Speaker
Connector type: 1x5 5-pin header, 2.0mm pitch
Connector location: JP3
Line-in Pin Header
Connector type: 1x4 4-pin header, 2.0mm pitch
Connector location: JP2
Pin Definition
1 FRONT_L+
2 FRONT_L-
3 FRONT_R+
4 GND
5 FRONT_R-
Pin Definition
1 FLIN_L
2 LIN_JD
3 FLIN_R
4 GND
1
5
1 4
