1.Test Configuration 2.Power Consumption Measurement
3.Test Data
System Configuration Description
Chassis CHASSIS NISE104 VER:A
CPU
Intel® Atom™ Processor D2550
(1M Cache, 1.86 GHz)
Memory
Apacer 2GB DDR3 1066MHz SODIMM
(78.A2GC9.AF0)
CPU board N/A
Motherboard NISB104 REV:B
HDD
SATA2 HDD 2.5 250GB 7200RPM
HTE725025A9A364
FDD N/A
CD-ROM N/A
CFast Transcend CFast 4GB (TS4GCFX5001)
Power Supply POWER ADAPTER FSP060-DBAB1
Add-on Card N/A
CPU Cooler NISE104 CPU HEATSINK SHYUNG SHUHN
System FAN N/A
Keyboard Microsoft Wired Keyboard 600
Mouse Microsoft Basic Optical Mouse
Purpose
The purpose of the power consumption test is to verify the power
dissipation of system, and the loading of power supply.
Test Equipment
PROVA CM-07 AC/DC CLAMP METER
Device Under Test
DUT: sys#1/
Test Procedure
1.Power up the DUT, boot into Windows 7 x32 Ultimate.
2.Entering standby mode (HDD power down).
3.Measure the power consumption and record it.
4.Run Burn-in test program to apply 100% full loading.
5.Measure the power consumption and record it.
Sys #1 Sys #1
+12V +24V
Full-Loading Mode 1.81A 0.96A
Total
21.72W 23.04W
Standby S1Mode 0.84A 0.45A
Total
10.08W 10.8W
