NISE 104 User Manual
Chapter 2: Jumpers and Connectors
PWR_BT/RET_BT/LED/SM BUS Pin Header
Connector type: 2x7 14-pin header, 2.0mm pitch
Connector location: JP8
1
13
142
Pin Definition Pin Definition
1 PWR_LED_N 2 PWR_LED_P
3 SATA_LED# 4 SATA_LED_P
5 SMB_C 6 SMB_D
7 3VSB 8 GND
9 PM_SLP_S3 10 PSON
11 POWER BOTTOM 12 GND
13 RESET BOTTOM 14 GND
LAN1 LED
Connector type: 2x2 4-pin header, 2.0mm pitch
Connector location: JP4
Pin Definition
1 LAN1_ACTPW
2 LAN1_LEDACT#
3 LAN1_LINK1G#
4 LAN1_LINK
1
2 4
3
