NISE 104 User Manual
Chapter 2: Jumpers and Connectors
SATA Connector
Connector type: Standard Serial ATAII 7P (1.27mm, SATA-M-180)
Connector location: CN6
Pin Definition
1 GND
2 SATA_TXP0_C
3 SATA_TXN0_C
4 GND
5 SATA_RXN0_C
6 SATA_RXP0_C
7 GND
71
SATA Power Connector
Connector type: 1x2 JST, 2-pin header, 2.5mm pitch
Connector location: J4
Pin Definition
1 GND
2 +5V
12
