NISE 104 User Manual
Chapter 4: BIOS Setup
H/W Monitor
This section is used to configure the hardware temperature, fan speed and
voltages.
Save & Exit
Advanced Chipset Boot SecurityMain
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2011 America Megatrends, Inc.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Monitor hardware status
Legacy OpROM Support
Launch Lan1 PXE OpROM
Launch Lan2 PXE OpROM
CPU Conguration
IDE Conguration
USB Conguration
Super IO Conguration
H/W Monitor
PPM Conguration
[Disabled]
[Disabled]
Save & Exit
Advanced Chipset Boot SecurityMain
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2011 America Megatrends, Inc.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Monitor hardware status
Pc Health Status
CPU Temperature
System Temperature
CPU FAN Speed
CPU:Vcore
+3.3V
+5V
+12V
: +33 C
: +35 C
: N/A
: +1.168 V
: +3.264 V
: +5.120 V
: +11.932 V
