4.9 Burst Setting and Manipulation
117
WF1973/WF1974
k) Noise gate oscillation
Noise having no cycle, the gate-on period is the oscillation period, and the gate-off period is
the oscillation stop period. Further, since noise has no phase, the stop level setting is always
enabled.
The next figure is an example of noise gate oscillation when the stop level is 0%.
Gate signal
Burst sync signal
Signal output
Gate on Gate onGate off
Oscillation Stop Oscillation
Stop level: 0%
