129
WF1973/WF1974
7. SPECIFICATIONS
The values of items marked with *1 are guaranteed values. All other values are either nominal
values or typical (typ.) values, and are not guaranteed.
Conditions unless otherwise mentioned are as follows: Continuous oscillation, 50 Ω load, 10
Vp-p/50 Ω amplitude setting, 0 V DC offset setting, auto-range, ±FS waveform amplitude
range, external addition off, AC voltage = RMS value measurement.
7.1 Oscillation Modes
Continuous, modulated, sweep, burst, sequence
7.2 Waveforms
7.2.1 Standard waveforms
Types Sine, square, pulse, ramp, parameter-variable
waveform, noise (Gaussian distribution), DC
Polarity Normal, inverted (selectable) (excluding DC)
Amplitude range −FS/0, ±FS, 0/+FS (selectable)
(excluding DC)
7.2.2 Arbitrary waveforms
Waveform length 4 K to 512 K words (2
n
, n = 12 to 19) or
2 to 10,000 control points (linear interpolation
between control points)
Total waveform saving capacity Up to 128 waveforms or 4 M words (combined total
for channels 1 and 2)
Saved to non-volatile memory
Waveform data amplitude resolution 16 bits
Sampling rate 120 MS/s
Polarity Normal, inverted (selectable)
Amplitude range −FS/0, ±FS, 0/+FS (selectable)
Output bandwidth 25 MHz, −3 dB
