7. SPECIFICATIONS
MULTIFUNCTION GENERATOR
7.3 Frequency, Phase
Frequency setting range
*2: Used through conversion to arbitrary waveform
Frequency setting resolution 0.01 µHz
Frequency setting by period Setting equivalent to inverse number of the set period
Frequency accuracy at shipping
*1
±(3 ppm of setting + 2 pHz)
Frequency aging rate
*1
±1 ppm/year
Phase setting range −1800.000° to +1800.000°(0.001° resolution)
7.4 Output Characteristics
7.4.1 Amplitude
Setting range 0 Vp-p to 20 Vp-p/open, 0 Vp-p to 10 Vp-p/50 Ω
Peak value combining waveform amplitude and DC
offset is limited to ±10 V/open or lower.
Setting resolution 999.9 mVp-p or lower 4 digits or 0.1 mVp-p
1 Vp-p or higher 5 digits or 1 mVp-p
Accuracy
*1
±(1% of amplitude setting [Vp-p] + 2 mVp-p)/open
Condition: 1 kHz sine, amplitude setting of 20 mVp-p/
open or higher
Setting units Vp-p, Vpk, Vrms, dBV, dBm
Range Auto, hold (selectable)
Maximum output voltage range: 20 Vp-p, 4 Vp-p
Amplitude attenuator range: 0 dB, −10 dB, −20 dB,
−30 dB
Waveform amplitude resolution Approx. 14 bits
Condition: Amplitude setting of 36 mVp-p/open or
higher
7.4.2 DC offset
Setting range ±10 V/open, ±5 V/50 Ω
Setting resolution ±499.9 mV or lower 4 digits or 0.1 mV
±0.5 V or higher 5 digits or 1 mV
Oscillation Mode Continuous, Modulated,
Sweep (Continuous,
Single-Shot)
Sweep (Gated Single-
Shot), Burst
Sequence
Waveform
Sine 0.01 µHz to 30 MHz 0.01 µHz to 10 MHz 0.01 µHz to 10 MHz
Square 0.01 µHz to 15 MHz 0.01 µHz to 10 MHz 0.01 µHz to 10 MHz
Pulse 0.01 µHz to 15 MHz 0.01 µHz to 10 MHz Not usable
Ramp 0.01 µHz to 5 MHz
0.01 µHz to 5 MHz
*2
Parameter-variable
waveform
0.01 µHz to 5 MHz
0.01 µHz to 5 MHz
*2
Noise Fixed to 26 MHz equivalent bandwidth
DC Frequency setting invalid
Arbitrary 0.01 µHz to 5 MHz
