Control (also with accessories)
FIGHTER 1110
For the Installer
12
Settings
HP-int
[P] Min interval in minutes between when the
heat pump starts.
Basic setting: 20.
Setting range: 20 – 60.
HWT-stop
[P] Stop temperature for water heater charging
when operating with additional heat only.
Basic setting: 50.
Setting range: 10 – 70.
11
XWW-stop
[P] Extra hot water stop temperature.
Basic setting: 65.
Setting range: 60 – 65.
XWW-int
[P] Interval in days for periodic extra hot water.
Basic setting: 14.
Setting range: 1 – 90.
12a
Shunt P
[P] Length of the shunt period in seconds.
Basic setting: 30 s.
Setting range: 10 - 60 s.
Shunt time
[P]Proportion of the running time per degree of
temperature variation.
Ex: 2°C x 10% x 30 sec = 6 sec.
This function compensates for the speed varia-
tion found on different shunt motors that may be
installed.
Basic setting: 10 %.
Setting range: 1 – 50 %.
12b*
* Only shown if a boiler sensor is connected.
DriftP: Shows the status of the operating pressostat
(1 = closed, 0 = open).
HP/MS: Shows the status of the high pressure presso-
stat/motor protection (1 = closed, 0 = open). Gives a
permanent alarm. Manual resetting of the motor pro-
tection.
LP: Shows the status of the low-pressure pressostat
(1 = closed, 0 = open). Gives a permanent alarm.
Brine-pump: Forced operation of brine pump. Change 0
to 1 using the Increase button at the same time as press-
ing the Operating mode button. 1 is then replaced by KB.
Return to normal mode after 10 days or with a restart.
Add-drift : If electric boiler operation is required (e.g.
before the collector installation is ready), switch 0 to 1, 3 or
5 and press the Operating mode button. The figure is then
supplemented with Add.
Selectable operating modes:
0 Compressor operation +3-step binary electrical sup-
plement. Recommended operating mode for accesso-
ry ETS 11.
1 3-step binary Add operation(after acknowledgement).
2 Compressor operation +7-step binary electrical sup-
plement.
3 7-step binary Add operation(after acknowledgement).
4 Compressor operation +3-step linear electrical supple-
ment.
5 3-step linear Add operation(after acknowledgement).
Select the right operating mode before Add-drift is activat-
ed. (Add-drift locks the operating mode function).
Only the operating modes 0 or 1 can be used if a boiler
sensor is installed.
13
14
15
Cal. Out [P] Calibration of outside sensors.
Room [P] Calibration of room sensor.
Brine In[P] Calibration of brine fluid flow sensor.
Brine Out [P] Calibration of the brine fluid return sensor.
Setting values for all quantities: -5 – +5.
HP-int 20 m
HWT-stop 50 °C
XWW-stop 65 °C
XWW-int 14d
Shunt P 30 s
Shunt time 10 %
DriftP 1
HP/MS 1 LP 1
Brine-pump 0
Add-drift 0
Cal.Out 0 Room 0
BrinIn 1 BrinO 1
