Nibe FIGHTER 1110 - List of Components

List of components 29
For the Installer
FIGHTER 1110
2 Miniature circuit-breaker
3 ** Operating thermostat, standby
4 Brine connection, in (f)
5 Brine connection, out (r)
6 Terminal block, hot water control
7 Service connection, high pressure
8 Switch, 1 – 0 –
9 Terminal block, incoming electric power
10 ** Contactor, electric module step 1
11 * Starting capacitor, compressor
12 * Start relay
13 Terminal block, pumps, high pressure
pressostat
14 * Operating capacitor, compressor
15 Outdoor sensor, connection
16 Heating medium pump
17 Evaporator
18 Condenser
19 ** Reversing valve
20 ** Contactor kit
21 Terminal block, sensor
22 Connection terminal, immersion heater kit
24 ** immersion heater 9 kW
25 ** Overheat protection
26 Motor protection, including reset
27 Compressor
28 Operating pressostat
29 Relay card with power supply unit
30 Terminal block, relay card
33 High pressure pressostat
34 CPU-unit, control system
35 Brine pump
41 Low pressure pressostat
42 Service connection, low pressure
48 Expansion valve
52 Safety valve, collector side
63 Particle filter
65 Drying filter
67 ** Contactor, electric module step 2
68 Contactor, compressor start
69 * Contactor, compressor operation
70 Connection, heating flow
71 Connection, heating return
76 Drainage for heating system
77 Venting valve, collector system
85 Level vessel
86 Temperature sensor, Brine In.
87 Temperature sensor, Brine Out.
88 Temperature sensor, hot water
89 Temperature sensor, WW-out, heating
medium flow
94 Temperature sensor WW-in, heat carrier
return
95 Type plate
96 Type plate, cooling section
97 *** Soft-start relay
