Nibe FIGHTER 1110 - Detailed Technical Data Tables

Cut-out value pressostat LP (bar) 1,5
Size 4 5 7 8,5 10 13 15
Cut-out value pressostat HP (bar) 27
Starting current (A) 42 24 24 24 26 26 26
Fuse, HP only (A) 16 10 10 10 16 16 16
Fuse (incl. imm. heater 9 kW) (A) 25 20 20 25 25 25 35
Connection, heating medium ext Ø (mm) 28
Brine flow (l/s) 0,25 0,35 0,48 0,58 0,65 0,75 0,86
Operating temp. brine system (°C) -5 – +20
Pressure drop, condenser (kPa) 2,7 2,6 3,4 3,2 4,4 3,1 4,1
Cut-out value operating pressostat (bar) 24
Output, brine pump (W) 130 130 170 170 250 250 250
Available press., brine system (kPa) 45 40 58 53 70 65 60
Operating voltage (V) 1 x 230*** 3 x 400 +N + PE 50 Hz
Max operating current, compressor (A) 8,0 3,6 5,5 6,7 7,9 9,0 11,0
Fuse (incl. imm. heater 6 kW) (A) 16 16 16 20 20 25 25
Output, heat medium pump (W) 75 75 75 75 170 170 170
Connection, collector fluid ext Ø (mm) 28 28 28 28 35 35 35
Refrigerant quantity (R407C) (kg) 1,4 1,7 2,2 2,4 2,4 2,5 2,6
Pressure drop, evaporator (kPa) 22 21 23 23 19 25 22
Heating medium flow (l/s) 0,10 0,13 0,18 0,22 0,26 0,31 0,36
Difference pressostat HP (bar) -7
Difference pressostat LP (bar) +1,5
Weight (kg) 170 175 195 200 215 225 230
Max temperature (flow- /return pipe) (°C) 60/50
Max pressure, brine system (bar) 3
Difference operating pressostat (bar) 5
Delivered/supplied power* at 0/35 °C **
4.8/1.0 6.0/1.3 8.8/1.9 10.3/2.2 11.7/2.5 14.6/3.1 17.0/3.7
IP 21
Technical specifications
FIGHTER 1110
For the Installer
34
* Compressor output only.
** Refers to the brine flow temperature/heat medium flow temperature in accordance with EN 255.
*** If accessory ETS 11 is installed, 3 x 400 V + N + PE 50 Hz is required.
Delivered/Supplied power* at 0/50 °C ** 3,9/1,2 4,8/1,5 7,1/2,2 8,5/2,5 9,9/2,9 12,6/3,6 14,8/4,3
Enclosure class IP 21
