General
FIGHTER 1110
For Home Owners
2
In order to get the ultimate benefit from your heat pump
FIGHTER 1110 you should read through the For Home
Owners section in this Installation and Maintenance
Instruction.
FIGHTER 1110 is a base heat pump for heating small hous-
es, apartment blocks and industrial premises. The ground,
rock or lakes can be used as the heat source.
FIGHTER 1110 is a Swedish made quality product offer-
ing a long life span and safe operation.
Installation date
Accessories: ............................
Electrical supplement ...... ■■
Hot water control ............ ■■
Oil supplement ................ ■■
Room control .................. ■■
Other .............................. ■■
The serial number (95), should always be stated with all corre-
spondence with NIBE.
089
___________
FIGHTER 1110-
__
kW
Installation engineers
Completedby the installer when the heat pump is installed
The type of brine fluid - Mixing proportion/freezing point
Active drilling depth/collector length
Commissioning checks
Temperature brine (flow/return)__ / __
Pump setting _
(Nominal temperature diff 2 - 5 °C)
Temperature heat medium (in/out) __ / __ Pump setting
__
(Nominal temperature diff 5 - 10 °C)
Settings
* Accessories ** Electric boiler mode (see menu 14).
Date ________ Signed ______________________________
Menu Basic
setting
2 Room * ..............
3 HM-r .............. 53
3 HW start * .............. 44
4 HT-r .............. -12
5 Curve slope .............. 9
5 Room comp. * .............. 4
5b WW-out min .............. 15
5b WW-out max .............. 45
9b HP-°min .............. 60
9b Add-min .............. 300
Menu Basic
setting
10 WW diff HP .............. 13
10 Diff HP-Add .............. 3
11 HP-int .............. 20
11 HWT-stop .............. 50**
12 XWW-stop .............. 65
12 XWW interval .............. 14
12b Shunt P * .............. 30
12b Shunt time * .............. 10
14 EP- operation ** ............
17 Parallel
