Control (also with accessories)
13
For the Installer
FIGHTER 1110
NOTE!
Enter the selected values on page 2
in this Installation instruction. The
details are important for
service work.
Settings
Service time: Change from 0 to 1 to speed up the
period of time by 60 times. Resets 8 minutes after the
last button was pushed.
Parallel: Current setting for the rotary potentiometer
Increase /Reduce heating to offset the heating curve
(parallel offset).
Man:Manual test of outputs. Change Man 0 to Man 1
or Man 2 to test different functions. Man 0 must be
set before you can exit the menu.
16
17
18
18b
It is important with some concrete floors to maintain
the right floor temperature during an initial period.
This is so the floor dries correctly.
FIGHTER 1110 has a function for this drying process.
The process can be divided into two periods where
the number of days and temperature are set for
respective periods. This setting is made on the chan-
nel 18. When the EHP interval 1 is set to 0 days the
function is not active.
FDP int 1
Shows the number of days at step 1.
WW-out
Shows the flow temperature at step 1.
FDP int 2
Shows the number of days at step 2.
WW-out
Shows the flow temperature at step 2.
It is possible to set the number of days from 1 to 10
and the temperature from 15 to 50 °C. Once the dry-
ing process is finished the FIGHTER 1110 automati-
cally returns to normal control.
If a power failure occurs during the drying process the
current time and temperature are stored. When the
power returns the drying process continues with the
settings that applied before the power failure. Thus
the drying process is carried out to a 100%.
Press the Channel button to return to display 9. You
then return to the original display 1. Press the Channel
button and keep it held down for about 7 seconds to
return to service mode, display 9.
FDP-int1 8d
WW-out 25 °C
FDP-int2 8d
WW-out 40 °C
Man 0
Relay 68 Start contactor, HP
Relay 69: Operating contactor, HP
Relay 35: brine pump
Relay xx: Reversing valve
rv
Relay 16: Heating medium pump
Relay L: Not active
Relay x1: Supplement 1
Relay x2: Supplement 2
Relay X3:Not active
Functions with oil-fired boiler
docking
Relay L:Not active
Relay S-: Shunt, closed.
Relay S+:Shunt, open.
Relay T3: External oil burner
Man1 68 0 69 0
35 0 xx 0
Man2 16 0 L 0
x1 0 x2 0 x3 0
Man2 16 0 L 0
S- 0 S+ 0 T3 0
Servicetime 0
Parallel 0
