Nice Spido Instructions And Warnings For Installation And Use

26 – ENGLISH
OPERATION SIGNALS ON THE DISPLAY
Symbol Function Description
Closing position programming The control unit waits for the user to conrm the closing position.
Opening manoeuvre Flashing: the automation is performing an opening position.
Closing manoeuvre Flashing: the automation is performing a closing manoeuvre.
Radio programming A procedure for memorising or deleting radio remote controls is under way.
Conguration not recognised
When entering one of the menus, the current conguration does not match any of
the values present in the table (e.g. an intermediate value was set through Oview or
app).
In the event of an anomaly, the OK LED will ash according to a specic sequence and the display will show the error code by alternating
the two characters of which it is composed.
Table 19
ERROR SIGNALS ON THE DISPLAY AND OK LED
Symbol OK LED red ashes Cause ACTION
1 ash
1-second pause
1 ash
Max closing not detected / Ground
not found
During the closing manoeuvre, the maximum limit was
reached without the ground being detected. Repeat
the “Programming the door opening and closing
positions” procedure (page 12).
2 ashes
1-second pause
2 ashes
Intervention of a photocell
At the start of the manoeuvre, one or more photocells
are blocking the movement; check whether there are
any obstacles. During the manoeuvre, this is normal if an
obstacle is present.
3 ashes
1-second pause
3 ashes
Intervention of the “Motor Force”
limiter
During the movement, the door experienced excessive
friction; identify the cause.
4 ashes
1-second pause
4 ashes
Triggering of the STOP input
At the start of the manoeuvre or during the movement,
the STOP input intervened; identify the cause.
5 ashes
1-second pause
5 ashes
Internal parameter memorisation error
Wait at least 30 seconds then try giving a command; if
the condition persists, it means that there is a serious
malfunction and the electronic board must be replaced.
6 ashes
1-second pause
6 ashes
The maximum number of
manoeuvres per hour limit has been
exceeded
Wait a few minutes until the manoeuvre limiter drops
below the maximum limit.
7 ashes
1-second pause
7 ashes
Error in the internal electric circuits
Disconnect all the power circuits for a few seconds
and then try giving a command again; if the condition
persists, it means there is a serious fault on the electronic
board or on the motor cabling. Perform any necessary
checks and replacements.
8 ashes
1-second pause
8 ashes
Command already present
Another command is already present. Remove the
command present to be able to send other commands.
8.3 SIGNALLING THROUGH WARNING LIGHT
Besides signalling the current manoeuvre, the warning light can reproduce the same signals as the OK LED in case of anomaly (with the
exception of the status change signal). The durations and signalling modes are the same as those of the OK LED with the exception of
the number of representations, as only one cycle will be reproduced (see “Table 19“).
l
This function can be congured on the FLASH (OUT1) output (see the “Setting the FLASH function” chapter on
page 19).
8.4 SIGNALS WITH COURTESY LIGHT
Besides signalling the current manoeuvre, the courtesy light reproduces the same signals as the OK LED in case of anomaly (with the
exception of the status change signal). The durations and signalling modes are the same as those of the OK LED with the exception of
the number of representations, as only one cycle will be reproduced (see “Table 19“).
