TECHNICAL SPECIFICATIONS
12
12 TECHNICAL SPECIFICATIONS
l
All technical specications stated in this section refer to an ambient temperature of 20°C (± 5°C). Nice S.p.A.
reserves the right to apply modications to the product at any time when deemed necessary, without altering
its functions and intended use.
Table 20
GEARMOTOR TECHNICAL SPECIFICATIONS
Description Technical specication
Product type
Electromechanical gearmotor for the automatic movement of garage doors for residential use, inclusive
of electronic control unit
Power supply
230Va (+/-10%) 50/60Hz
Power supply /V1
120Va (+/-10%) 50/60Hz)
Maximum force 600 N
Minimum force 300 N
Maximum power consumption
(W)
350
Nominal power consumption
(W)
150
Maximum speed (m/s) 0,20
Protection rating (IP) 40
Operating temperature (min/
max °C)
-20°C ... +55°C
Insulation class I
Maximum no. of cycles/day 40
Maximum continuous operating
time
4 minutes
Dimensions (mm) 192x344x90
Weight (kg) 3,8
Emergency power supply With optional accessory PS124
Courtesy light Integrated with LED
Warning light output[Note 1] For 1 ELDC LED ashing warning light (max 200 mA)
PHOTOTEST output
Output for the connection of photocells in Phototest mode (max 2 transmitters per photocell) (max 15
mA)
STOP input
For normally closed or normally open contacts, 8.2 KΩ xed resistor contacts or OSE optical devices
with self-learning function (any variation from the memorised status triggers the “STOP” command)
SbS input For normally open contacts (closing of the contact triggers the STEP-BY-STEP command)
PHOTO input For normally closed contacts (the contact’s opening triggers the photocell reopening command)
Radio ANTENNA input 52 Ω for RG58-type cable or similar
Programming input For 1 OVIEW programmer with IBT4N interface
Programmable functions 7 adjustable functions
Self-learning functions
Self-learning of the type of “STOP” device (Normally Open, Normally Closed contact or 8.2 kΩ resistor)
Calculation of the slowdown and partial opening points
Use in highly acid, saline
or potentially explosive
atmosphere
No
Note 1 The output can be programmed with other functions (see the “Setting the FLASH function” chapter on page 19) or through
the Oview programmer.
