Setup Tools
5 Setup Tools
Setup Tools includes options to load or save parameters to a backup file, set the starter's
network address, check the status of the inputs and outputs, reset the thermal models or
test operation using the Run Simulation.
To access the Setup Tools, press MENU to open the Menu then select Setup Tools.
5.1 Command Source
The soft starter can be started and stopped via the digital inputs, remote keypad,
communication network or smart card. The command source can be set via the Setup
Tools, or using parameter 1A Command Source.
If the remote keypad is installed, the LOCAL/REMOTE button provides shortcut access to
the Command Source function in Setup Tools.
5.2 Commissioning
Commissioning lets the starter be started and stopped via the local keypad. Use the
and
buttons to select a function, then press to send the selected command to the
starter. The available functions are:
• Quick stop (coast to stop)/Reset
• Start
• Stop
5.3 Run simulation
The run simulation simulates a motor starting, running and stopping to confirm that the soft
starter and associated equipment have been installed correctly.
NOTE
The soft starter must be disconnected from mains voltage.
The simulation is only available when the soft starter is in Ready state.
To use the run simulation:
1. Press MENU to open the menu then select Setup Tools.
2. Scroll to Run Simulation and press .
Ready
3. Apply a start command from the selected command
source. The soft starter simulates its pre-start checks
and closes the main contactor relay. The Run LED
flashes.
Pre-Start Checks
MENU to Continue
NOTE
If mains voltage is connected, an error message is
shown.
ATTENTION!
Remove Mains Volts
4. Press . The soft starter simulates starting.
Starting X:XXs
5. Press . The soft starter simulates running.
Running
27
