Logs
6 Logs
The Logs Menu provides information on events, trips and starter performance.
To access the Logs Menu on the local keypad, press MENU to open the Menu then select
Logs. On the remote keypad, press LOGS.
6.1 Event Log
The Event Log stores details of the starter's most recent trips, warnings, and operations
(including starts, stops and configuration changes).
Event 1 is the most recent and event 384 is the oldest stored event.
NOTE
Events in the event log are timestamped based on time elapsed since control
power was last applied. The timestamp resets to zero when control power is
cycled.
NOTE
The event log can be exported to an external file for analysis away from the starter.
See USB Save & Load on page 28 for details.
6.2 Counters
The counters store statistics on the starter's operation:
• Hours run (lifetime and since counter last reset)
• Number of starts (lifetime and since counter last reset)
• Number of times the thermal model has been reset
To view the counters:
1. Open the Logs.
2. Scroll to counters and press
.
3. Use the
and buttons to scroll through the counters. Press to view details.
4. To reset a counter, press
then use the and buttons to select Reset/Do Not
Reset. Press STORE to confirm the action.
To close the counter and return to the Logs, press
.
6.3 QR Code
The soft starter can generate a QR code which allows a smartphone to display key
information about the starter, including serial number, firmware versions and installed
options, plus details of the starter’s three most recent trips. This information can be useful
when requesting assistance from your local supplier.
NOTE
You must install the soft starter support app in order to read the QR code. Contact
your local supplier for further information.
32
