Programmable Parameters
9.10 8 Relay Outputs
8A – Relay A Function
Ready The relay is closed when the starter is in Ready state.
The Run output closes when the soft start is complete
(when the starting current falls below 120% of the
programmed motor full load current) and remains
closed until the beginning of a stop (either soft stop or
The relay closes when the starter issues a warning
(see 6 Protection Action on page 50).
The relay closes when the starter trips (see 6
Protection Action on page 50).
Low Current Flag The relay closes when the low current flag activates
while the motor is running (see parameter 8G Low
The relay closes when the high current flag activates
while the motor is running (see parameter 8H High
Flag
The relay closes when the motor temperature flag
activates (see parameter 8I Motor Temperature Flag).
The relay closes when control power is applied. The
relay opens if the soft starter trips or if control power
Description: Selects the function of Relay A. Relay A is a changeover relay.
8B – Relay A On Delay
Range: 0:00 - 5:00 (minutes:seconds) Default: 0 second
Description: Sets the delay for changing the state of Relay A.
8C – Relay A Off Delay
Range: 0:00 - 5:00 (minutes:seconds) Default: 0 second
Description: Sets the delay for changing the state of Relay A.
8D – Relay B Function
Options: Off Low Current Flag
Ready High Current Flag
Run (default) Motor Temperature Flag
Warning Trip Failsafe
Trip
Description: Selects the function of Relay B (normally open). See parameter 8A Relay A
Function.
8E – Relay B On Delay
Range: 0:00 - 5:00 (minutes:seconds) Default: 0 second
Description: Sets the delay for closing Relay B.
8F – Relay B Off Delay
Range: 0:00 - 5:00 (minutes:seconds) Default: 0 second
Description: Sets the delay for re-opening Relay B.
55
