Programmable Parameters
9 Programmable Parameters
9.1 Main Menu
The main menu lets you view and change programmable parameters that control how the
soft starter operates.
To open the main menu, press the MENU/ENTER button then scroll to Main Menu and
press MENU/ENTER again.
NOTE
Parameters for smart card functions are only visible in the parameter list if the
smart card is installed.
9.2 Altering Parameter Values
To change a parameter value:
scroll to the appropriate parameter in the main menu and press
to enter edit
mode.
to alter the parameter setting, use the
and buttons. Pressing or once
will increase or decrease the value by one unit. If the button is held for longer than
five seconds, the value will increase or decrease at a faster rate.
to save changes, press STORE. The setting shown on the display will be saved and
the keypad will return to the parameter list.
to cancel changes, press EXIT. The keypad will ask for confirmation, then return to
the parameter list without saving changes.
9.3 Adjustment Lock
You can prevent users from altering parameter settings by turning on the adjustment lock
(parameter 10G Adjustment Lock).
If a user attempts to change a parameter value when the adjustment lock is active, an error
message is displayed:
Access Denied
Adj Lock is On
9.4 Parameter List
Parameter Group
Default Setting
1
Motor Details
1A
Command Source
Digital Input
1B
Motor Full Load Current
Model dependent
1C
Locked Rotor Time
00:10 (mm:ss)
1D Locked Rotor Current 600%
1E
Motor Service Factor
105%
1F
Reserved
2
Motor Start/Stop
2A
Start Mode
Constant Current
2B
Start Ramp Time
00:10 (mm:ss)
2C
Initial Current
200%
2D
Current Limit
350%
2E
Adaptive Start Profile
Constant Acceleration
2F
Stop Mode
TVR Soft Stop
42
