System Design
3.13 Fuse Selection for Type 2 Coordination
Type 2 coordination is achieved by using semiconductor fuses. These fuses must be able
to carry motor start current and have a total clearing I
2
t less than the I
2
t of the soft starter
SCRs.
When selecting semiconductor fuses for soft starter, use the I
2
t values in the table.
For further information on selecting semiconductor fuses, contact your local distributor.
I
2
t values for Type 2 coordination
Model
SCR I
2
t (A
2
s)
0024B
1150
0042B
7200
0052B
0064B
15000
0069B
0105B
80000
0115B
0135B
125000
0184B
320000
0200B
0229B
0250B
0352B
202000
0397B
0410B
320000
0550B
781000
0580B
3.14 Specifications
Supply
Mains voltage (L1, L2, L3)
xxxxX-V5 ................................................................................ 200~525 VAC (± 10%)
xxxxX-V7 ................................................................................ 380~600 VAC (± 10%)
Control voltage (A1, A2, A3)
xxxxX-xx-C1 (A1, A2) ....................................... 110~120 VAC (+10%/-15%), 600 mA
xxxxX-xx-C1 (A2, A3) ....................................... 220~240 VAC (+10%/-15%), 600 mA
xxxxX-xx-C2 (A1, A2) ..................................................... 24 VAC/VDC (± 20%), 2.8 A
Mains frequency ............................................................................. 50 Hz~60 Hz5 Hz)
Rated insulation voltage ..................................................................................... 600 VAC
Rated impulse withstand voltage .............................................................................. 6 kV
Form designation .............. Bypassed or continuous, semiconductor motor starter form 1
Short circuit capability
Coordination with semiconductor fuses ................................................................. Type 2
Coordination with HRC fuses ................................................................................ Type 1
Electromagnetic capability (compliant with EU Directive 2014/35/EU)
EMC Immunity .......................................................................................... IEC 60947-4-2
EMC Emissions ........................................................................... IEC 60947-4-2 Class B
16
