Nidec Digistart D4 User Manual

System Design
Model
Nominal
Rating (A)
Short Circuit
Rating @ 480
VAC max.
Listed fuse rating
(A)
##3
Fuse class
##2
0184B
184
65 kA
200
J, T
0200B 225 225
0229B
229
250
0250B
250
300
0352B
352
400
0397B
397
450
Any
0410B
410
450
(J, T, K-1,
0550B
550
600
RK1, RK5)
0580B
580
600
• Circuit breakers – High fault short circuit current
Suitable for use on a circuit capable of delivering not more than 65,000 rms symmetrical
amperes, 480 VAC maximum, when protected by circuit breaker models noted in ##4, ##5
or ##6.
Model
Nominal
Rating (A)
Breaker 1: Eaton
(rating, A)
##4
Breaker 2: GE
(rating, A)
##5
Breaker 3: LS
(rating, A)
1
##6
0024B
24 HFD3030 (30 A)
SELA36AT0060
(60 A)
UTS150H-xxU-040
(40 A)
0042B
42 HFD3050 (50 A)
UTS150H-xxU-050
(50 A)
0052B
52 HFD3060 (60 A)
UTS150H-xxU-060
(60 A)
0064B
64
HFD3100 (100 A)
SELA36AT0150
(150 A)
UTS150H-xxU-100
(100 A)
0069B
69
0105B
105
HFD3125 (125 A)
UTS150H-xxU-125
(125 A)
0115B
120
0135B
135 HFD3150 (150 A)
UTS150H-xxU-150
(150 A)
0184B 184
HJD3250 (250 A)
SFLA36AT0250
(250 A)
UTS250H-xxU-250
(250 A)
0200B
225
0229B
229
0250B 250 HKD3300 (300 A)
SFLA36AT0400
(400 A)
UTS400H-xxU-300
(300 A)
0352B
352
HLD3400 (400 A)
SFLA36AT0600
(600 A)
UTS400H-xxU-400
(400 A)
0397B
397
0410B 410
HLD3600 (600 A)
UTS600H-xxU-600
(600 A)
0550B 550
UTS800H-xxU-800
(800 A)
0580B 580
SGLA36AT0600
(600 A)
UTS800H-NG0-800
1
For LS breakers, xx represents FM, FT or AT.
