Nidec Digistart D4 User Manual

Programmable Parameters
9.9 7 Inputs
7A – Input A Function
Options:
Command Override:
Network
Overrides the setting of 1A and sets the command
source to the communications network.
Command Override:
Digital
Overrides the setting of 1A and sets the command
source to the digital inputs.
Command Override:
Keypad
Overrides the setting of 1A and sets the command
source to the remote keypad.
Input Trip (N/O)
(default)
A closed circuit across 13, 14 trips the soft starter.
Input Trip (N/C)
An open circuit across 13, 14 trips the soft starter.
Emergency Mode
A closed circuit across 13, 14 activates emergency
mode. When the soft starter receives a start
command, it will continue to run until a stop command
is received, ignoring all trips and warnings.
Description: Selects the function of Input A.
7B – Input A Trip
Options:
Always Active
A trip can occur at any time when the soft starter is
receiving power.
Operating Only
(default)
A trip can occur while the soft starter is running,
stopping or starting.
Run Only
A trip can only occur while the soft starter is running.
Description: Selects when an input trip can occur.
7C – Input A Trip Delay
Range: 0:00 - 4:00 (minutes:seconds) Default: 0 second
Description: Sets a delay between the input activating and the soft starter tripping.
7D – Input A Initial Delay
Range: 00:00 - 30:00 (minutes:seconds) Default: 0 second
Description: Sets a delay before an input trip can occur. The initial delay is counted from
the time a start command is received. The state of the input is ignored until
the initial delay has elapsed.
7E – Input B Function
Options: Input Trip (N/O) (default)
Input Trip (N/C)
Emergency Mode
Description: Selects the function of Input B. See parameter 7A Input A Function for
details.
7F – Input B Trip
Options: Always Active
Operating Only (default)
Run Only
Description: Selects when an input trip can occur.
53
