Programmable Parameters
7G – Input B Trip Delay
Range: 0:00 - 4:00 (minutes:seconds) Default: 0 second
Description: Sets a delay between the input activating and the soft starter tripping.
7H – Input B Initial Delay
Range: 00:00 - 30:00 (minutes:seconds) Default: 0 second
Description: Sets a delay before an input trip can occur. The initial delay is counted from
the time a start command is received. The state of the input is ignored until
the initial delay has elapsed.
7I – Reset/Enable Logic
Options: Normally Closed (default)
Normally Open
Description: Selects whether the reset input (10, 11) is normally open or normally closed.
NOTE
If the reset input is active, the starter will not operate.
7J – Input A Name
Options:
Input A Trip (default)
Controller
Low Pressure
PLC
High Pressure
Vibration Alarm
Pump Fault Field Trip
Low Level Interlock Trip
High Level
Motor Temperature
No Flow
Motor Protection
Starter Disable
Feeder Protection
Custom Message
Description: Selects a message for the keypad to display when Input A is active.
The custom message can be loaded via the USB port. See USB Save & Load on page 28
for details.
7K – Input B Name
Options:
Input B Trip (default)
Controller
Low Pressure
PLC
High Pressure
Vibration Alarm
Pump Fault
Field Trip
Low Level
Interlock Trip
High Level
Motor Temperature
No Flow
Motor Protection
Starter Disable
Feeder Protection
Custom Message
Description: Selects a message for the keypad to display when Input B is active.
54
