Nidec Digistart D4 User Manual

System Design
3 System Design
3.1 Feature List
Streamlined setup process
• Configuration profiles for common
applications
• Built-in metering and inputs/outputs
E
asy to understand interface
• Multi-language menus and displays
• Descriptive option names and feedback
messages
• Real-time performance graphs
S
upports energy efficiency
• IE3 compatible
• 99% energy efficient when running
• Internal bypass
• Soft start technology avoids harmonic
distortion
E
xtensive range of models
• 24 A~580 A (nominal)
• 200~525 VAC
• 380~600 VAC
V
ersatile starting and stopping options
• Adaptive Control
• Constant Current
• Current Ramp
• Timed voltage ramp soft stop
• Coast To Stop
Customisable protection
• Motor overload
• Excess Start Time
• Undercurrent
• Overcurrent
• Current imbalance
• Input Trip
• Motor thermistor
E
xtensive input and output options
• Remote control inputs
(2 x fixed, 2 x programmable)
• Relay outputs
(1 x fixed, 2 x programmable)
• Analog output
O
ptional features for advanced
applications
• Smart cards
• Communication options: DeviceNet,
Ethernet/IP, Modbus RTU, Modbus
TCP, Profibus, Profinet
3.2 Model Code
0
0
6
9
–
–
Control voltage
C1 = 110~120 VAC or 220~240 VAC
C2 = 24 VAC/VDC
Mains voltage
V5 = 200~525 VAC
V7 = 380~600 VAC
Bypass
B = internally bypassed
Nominal current rating
7
D4-
