Nidec Digistart D4 User Manual

Programmable Parameters
Parameter Group
Default Setting
2G
Stop Time
00:00 (mm:ss)
2H
Adaptive Stop Profile
Constant Deceleration
2I
Adaptive Control Gain
75%
2J
Multi Pump
Single Pump
2K
Start Delay
00:00 (mm:ss)
5
Protection Levels
5A
Current Imbalance
30%
5B
Current Imbalance Delay
00:03 (mm:ss)
5C
Undercurrent
20%
5D
Undercurrent Delay
00:05 (mm:ss)
5E
Overcurrent
400%
5F Overcurrent Delay 00:00 (mm:ss)
5G
Excess Start Time
00:20 (mm:ss)
5H
Restart Delay
00:10 (mm:ss)
5I
Starts per Hour
0
5J
Phase Sequence
Any Sequence
6
Protection Actions
6A
Auto-Reset Count
0
6B
Auto-Reset Delay
00:05 (mm:ss)
6C
Current Imbalance
Soft Trip and Log
6D
Undercurrent
Soft Trip and Log
6E
Overcurrent
Soft Trip and Log
6F
Excess Start Time
Soft Trip and Log
6G
Input A Trip
Soft Trip and Log
6H
Input B Trip
Soft Trip and Log
6I
Network Communications
Soft Trip and Log
6J
Remote Keypad Fault
Soft Trip and Log
6K
Frequency
Soft Trip and Log
6L
Phase Sequence
Soft Trip and Log
6M
Motor Overtemperature
Soft Trip and Log
6N
Motor Thermistor Circuit
Soft Trip and Log
7
Inputs
7A
Input A Function
Input Trip (N/O)
7B
Input A Trip
Operating Only
7C
Input A Trip Delay
00:00 (mm:ss)
7D
Input A Initial Delay
00:00 (mm:ss)
7E Input B Function Input Trip (N/O)
7F
Input B Trip
Operating Only
7G
Input B Trip Delay
00:00 (mm:ss)
7H
Input B Initial Delay
00:00 (mm:ss)
7I
Reset/Enable Logic
Normally Closed (N/C)
43
