Nidec Digistart D4 User Manual

Keypad and Feedback
Starter status screen
69.0 A
Motor running current
Running
Starter status
69.0 A 415 V
Parameter 10H User Parameter 1 and parameter 10I User
Parameter 2
Current
The current screen shows real-time line current on each phase.
Phase Currents
000.0A 000.0A 000.0A
Last Start Information
The last start information screen shows details of the most recent successful start:
• start duration (seconds)
• maximum start current drawn (as a percentage of motor full load current)
• calculated rise in motor temperature
Last start 010 s
350 % FLC
∆
Temp 5%
User configurable screen
The programmable screen can be configured to show the most important information for
the particular application. Use parameters 10J ~ 10M to select which information to display.
Mains Frequency 59.7 Hz
Motor pf 0.95
Motor Power 37.0 kW
Motor Temperature 85%
Performance Graph
The performance graph provides a real-time display of operating performance. Use
parameters 10B~10E to format the graph.
The display on the main keypad shows information for motor current.
05050.C
000.0 A
0-400%
If a remote keypad is connected, press GRAPHS to change the graph data. The graph can
show:
• motor current
• motor temperature
• motor pf
• analog input data from the smart card (if installed)
35
