Nidec Digistart D4 User Manual

Programmable Parameters
10G – Adjustment Lock
Options:
Read & Write
(default)
Allows users to alter parameter values in the main
menu.
Read Only
Prevents users altering parameter values in the main
menu. Parameter values can still be viewed.
Description: Selects whether the keypad will allow parameters to be changed via the
main menu.
10H – User Parameter 1
Options:
Blank
Displays no data in the selected area, allowing long
messages to be shown without overlapping.
Current (default)
Average rms current across all three phases
Mains Frequency
The average frequency measured on three phases.
Motor pf
The motor's power factor, measured by the soft
starter.
Motor Temperature
(%)
The motor's temperature, calculated by the thermal
model.
Hours Run
The number of hours the motor has run via the soft
starter.
Number of Starts
The number of starts the soft starter has completed
since the start counter was last reset.
Pump Pressure
The pressure at the pump, as configured in
parameters 30B~30D. This information is only
available if the smart card is installed.
Pump Flow
The flow at the pump, as configured in parameters
30F~30K. This information is only available if the
smart card is installed.
Well Depth
The depth of the well, as configured in parameters
30M~30O. This information is only available if the
smart card is installed.
Pump Temperature
The pump temperature, as measured by the PT100.
This information is only available if the smart card is
installed.
Analog Output Value
The value of the analog output (see parameters
9A~9D).
Heatsink
Temperature
The soft starter's temperature, measured at the
heatsink.
Bypass Model (%)
The percentage of thermal capacity remaining in the
bypass contactor.
SCR Temperature
The temperature of the SCRs, calculated by the
thermal model.
Rating Capacity (%)
The thermal capacity available in the soft starter for
its next start.
Description: Selects which information will be displayed on the main monitoring screen.
10I – User Parameter 2
Options: See parameter 10H User Parameter 1 for details. Default: Mains Frequency
Description: Selects which information will be displayed on the main monitoring screen.
See parameter 10H User Parameter 1 for details.
58
