Nikon A1 User Manual

82
Capturing High-Speed ZT Series Images
(Resonant Scanner)
26
Chapter 26. Capturing High-Speed ZT Series Images (Resonant Scanner)
26.1 Perform Steps 25.1 to 25.3 in Chapter 25, “Capturing High-Speed Images.”
26.2 Open the ND Acquisition dialog box.
(1) Click the
[XYZ Time...] button to
open the ND Acquisition dialog box.
26.3 Determine the Z acquisition range of the ZT series.
1) Without perfect focus system
(1) Click the Z tab.
(2) Click the
[Defined top & bottom] button.
(3) Click the [Reset] button.
1)-(2)
1)-(3)
1)-(1)

Nikon A1 Specifications

General

Type	Confocal Microscope
Software	NIS-Elements
Laser Lines	405 nm, 488 nm, 561 nm, 640 nm
Detector	GaAsP PMT detectors
Imaging Modes	Confocal, Spectral, FRAP
Scanning Method	Galvanometer-based scanning
Objectives	Compatible with Nikon CFI objectives
Dimensions	Varies with configuration
Weight	Varies with configuration
Laser	Multiple laser lines available
