43
Image Display Function
15
Chapter 15. Image Display Function
15.1 Channel display switch
(1) Click a tab on the
task bar to switch channels to be displayed.
The [Custom] tab allows you to freely select
images for overlapping.
Right-click on the [Custom] tab and select
images from the list.
(2) Clicking the
[Split Components] button
displays all channels at the same time.
Reclicking this button restores the previous
display.
15.2 Multidimensional image display switch
(1) Clicking an item on the
scale bar allows you to view each series
image. Clicking
or shifts the image
to the next one.
(2) Use
to play back the image. Reclicking
this button stops playback. Use
to adjust the playback speed.
Use
for real-time playback (at the speed
of actual image acquisition) and use
for
fastest playback.
(3) Clicking the
[Show Tiled View] button
displays series images in tiling mode.
Use
to select series images for tiling.
