Nilfisk-Advance Convertamatic 24 Service Manual

Nilfisk-Advance Convertamatic
™
24/26/28/32 & BA 625, 725, 825
Cylindrical and Disc
PM Checklist
Defect Codes
Customer A needs adjustment
B binding
Address C dirty or contaminated
D damaged, bent or torn
City St Zip L leaks
M missing
Model Serial Hours W worn out
Ref
OPERATIONAL INSPECTION ITEMS
OK
Defect Codes
(circle)
Does
Not
Work
1 Drive Paddle Operation (check for Fwd/Rev Drive & any neutral creep) A B D
2 Drive System Performance (Speed Changes Min/Max) noisy sluggish
3 Scrub System (Raise/Lower, Brush Motor On/Off & Optional Brush Remove Feature) A B D
4 Scrub Brush Pressure settings (1-3) A B
5 Squeegee System (Raise/Lower & Squeegee Tool pickup Performance) A B D
6 Vac Performance (Sealed water lift & 1” open hole adapter, 24v-56/9) C L W
7 Solution Control (On/Off Manual /Auto and Flow Volume settings 1,2 &3) A B L
8 Battery Charger (Auto turn ON & OFF) D
9 Main Controller Special Program Options (see SVR manual 56043098). Check all applicable
machine settings. Examples: Scrub mode pressure settings, SVR test mode, low voltage cutout
etc.
A
Ref
VISUAL INSPECTION ITEMS
Comments OK
Defect Codes
(circle)
Does
Not
Work
10 Scrub Brushes, check for wear and rotate D M W
11 Scrub Brush Motor(s), check for carbon brush wear 500 Hours B C W
12 Scrub Brush Motor(s), check gearboxes (disc) B D L
13 Brush Drive Plate Retainer Clips & flex couplers (disc) C D M
14 Scrub Deck Lift Motor, Skirt & Side Wheel D M W
15 Solution Solenoid Valve C L W
16 Solution Pump & Hoses C L W
17 Solution Tank, Delivery Hoses & Filter clean filter screen C L
18 Vacuum Motor Carbon Brushes (wear limit 3/8”) 300 Hours B C W
19 Vacuum motor inlet filter (located in recovery tank) clean screen C D M
20 Recovery Tank Cover Gasket L M W
21 Recovery Tank Drain Hose & Cap C D L
22 Squeegee Pick-Up Hose back flush C D L
23 Squeegee Tool & Blades (clean, rotate & adjust) A D W
24 Squeegee Tool lift cable & mount Wheels (lubricate) two side & one floor A D W
25 Battery Condition (load test, clean & water) C W
26 Drive Wheel Trans Axle Motor Check Carbon Brushes 500 Hours B C D W
27 Trans Axle Drive Tires tread wear W
28 Rear chassis Caster Wheel (Lubricate) tread wear W
NOTE: For additional service information see service manual form number 56043098 and operator manual form
numbers 56041591-56041596 & 56041703.
WORK COMPLETED BY: ACKNOWLEDGED BY:
Service Technician Signature Date Customer Signature Date
revised 5/07
