5. Step 0
Programming: To optimize the stripping time use Step 0 to enter the outside diameter of the wire.
After starting the stripping cycle, the stripping blades immediately close to the selected outside
diameter before they start cutting with the programmed feed rate.
Program Step Selecting and Entering
Choose the preset diameter (∅
∅∅
∅3.00)
and
enter the cable outside diameter
+0.5mm e.g. 6.50 mm.
3.00 – 6.5 - Enter
d
D
At missing entry of Step 0: In case Step 0 is not programmed the control uses the largest diam-
eter stored in the current program. In this example the diameter in Step 3 is the largest one stored
in the memory. This avoids the blades do not close with a high feed rate through the different lay-
ers.
Rule: The diameter in Step 0 can never be smaller than the largest diameter determined in the
current program.
4. Step 1
Program Step Selecting and Entering
Choose the preset diameter (∅
∅∅
∅1.00)
and
enter the cable diameter
e.g. 0.90mm
Choose the preset stripping length (3.0)
and enter
the stripping length
e.g. 6.0mm.
1.00 – 0.9 – Enter
3 3.0 – 6 – Enter
Avoid damaging of the cable: select during programming a slightly larger strip-
ping diameter and correct it downward after the stripping test.
5. Step 2
Program Step Selecting and Entering
Choose the preset diameter (∅
∅∅
∅2.00)
and
enter the cable diameter
e.g. 3.65mm
Choose the preset stripping length (6.0) and
enter the stripping length e.g. 16.0mm.
1.90 – 3.65 – Enter
9.0 - 16 – Enter
