Machine Description
The microprocessor controlled coaxial cable stripping machine ST730T is designed to
strip wires and coaxial cables up to 7 mm outer diameter and strip lengths up to 30 mm in
up to 9 steps. Even single insulated wires can be processed accurately. The ST730T is
capable of storing up to 999 programs. Cable parameters can easily be stored and re-
called at any time. Following a brief summary of the machine features:
• The operations of the 9 stripping steps can be done in a single fixation. This increases the pro-
cessing speed and saves time.
• High reproducibility of the strip length when properly handled.
• Different wire diameters can be processed without any mechanical settings.
• Stripping and corrective values can be directly set and stored.
• Any stored stripping parameters can be selected and will remain in memory even in the event of
blade changes or power failures.
• The stripping diameters can be precisely adjusted with an accuracy of up to 1/1000 mm.
• The ST730T is easy to operate and enables the user to be familiar with the process within a few
minutes.
• The precision of all components together with the microprocessor control assure the highest
process reproducibility.
• The RS 232 interface makes the ST730T compatible with various peripheral devices.
Unpacking the ST730T
• Take the ST730T out of the package carefully and remove the packing material.
• The packaging should be kept for future handling purposes.
• In case the ST730T is to be shipped by post than the transportation locks (foamed plastic (1)
between the stripping head ( 5 ) and the clamping jaws (4)) must be in place (Fig. 2, page 11).
