Configure a G-240W-C indoor ONT
108
7368 ISAM ONT G-240W-C Product Guide
3FE-46256-AAAA-TCZZA Issue: 01
Figure 45 US Classifier Policy window
Table 35 describes the fields in the US Classifier Policy window.
Table 35 US Classifier Policy parameters
2 Select a tunnel interface.
3 Enter a VLAN ID and priority level.
4 Click Save.
5 To delete a policy, click the Delete option for the applicable policy in the policy table.
A policy can only be deleted if it is not associated with any classifier rules.
6 Select Network > US Classifier from the top-level menu in the GPON Home Gateway
window, and select the Classifier tab, as shown in Figure 46.
Field Description
Tunnel Type The tunnel type is set to GRE and cannot be modified.
Tunnel Interface Choose a tunnel interface from the drop-down menu: No Tunnel, GRE
Tunnel, or LAN traffic.
VLAN ID Enter a VLAN ID (0-4094).
VLAN Tag This field is not configurable. The VLAN tag is set to 8100.
VLAN Priority Enter a VLAN priority level (0 to 7). A lower number indicates a higher
priority.
IP TOS/DSCP This field is not configurable. All tunnel packets are generated with a
default DSCP value (usually 0).
Release 06.01.00 | March 2019 | Edition 12
