Nokia RM-596 - WLAN Self Test in Phoenix; Bluetooth BER Test in Phoenix

7. To run the tests, click Start.
Figure 15 Bluetooth and FM radio self tests in Phoenix
WLAN self test in Phoenix
Prerequisites
A flash adapter (or phone data cable) connected to a PC with Phoenix service software is required.
Steps
1. Place the phone in the flash adapter or connect data cable to phone.
2. Start Phoenix service software.
3. Choose File → Scan Product.
4. From the Mode drop-down menu, set mode to Local.
5. Choose Testing → Self Tests.
6. In the Self Tests window check the following WLAN test:
•
ST_WLAN_TEST
7. To run the test, click Start.
Bluetooth BER test in Phoenix
Prerequisites
JBT-9, or SB-6 Bluetooth test box (BT-box) is required to perform a BER test. If a BT-box is not available,
Bluetooth functionality can be checked by transferring a file to another Bluetooth phone.
Steps
1. Connect data cable to phone.
2. Start Phoenix service software.
