Table 10 Calibration value limits
Parameter Min. Max.
ADC Offset -14 14
ADC Gain 12000 14000
BSI Gain 1100 1300
VBAT Offset 2450 2800
VBAT Gain 15000 21900
VCHAR Gain N/A N/A
IBAT (ICal) Gain 7750 12250
9. Click Read, and confirm that the new calibration values are stored in the phone memory correctly. If the
values are not stored to the phone memory, click Write and/or repeat the procedure again.
10. To end the procedure, close the
Energy Management Calibration
window.
RM-721; RM-722
BB Troubleshooting and Manual Tuning Guide
Page 3 – 64 COMPANY CONFIDENTIAL Issue 1
