CA-158RS RF tuning cable
Product-specific adapter cable for RF tuning.
•
Table 7 Attenuation values
Band Attenuation Rx
GSM 850/900 0.30 dB
GSM 1800 0.38 dB
GSM 1900 0.41 dB
WCDMA I (2 GHz) 0.45 dB
CA-31D USB cable
The CA-31D USB cable is used to connect FPS-21 to a PC. It is included
in the FPS-21 sales package.
CA-89DS Cable
Provides VBAT and Flashbus connections to mobile device
programming adapters.
RM-721; RM-722
Service Devices and Service Concepts
Page 2 – 10 COMPANY CONFIDENTIAL Issue 1
Copyright © 2011 Nokia. All rights reserved.
