Introduction
Phone description
RAP3Gv4 is the main digital baseband ASIC in the device. It contains functionality for both WCDMA and GSM
EDGE. The cellular baseband is constructed around Radio Application Processor (RAP3GS2v4) and mixed signal
ASIC PEARL_J. RAP3GS2v4 is used as a single chip solution, which means that all UI components are connected
to RAP3GS2v4.
N2200 is the main audio and energy management controller for the phone. The mixed-signal functionality
is in one mixed-signal ASIC. N2200 includes blocks for charger control, SMPS power supplies for VCORE, VIO
and LEDs, linear regulators for RF and BB supplies, level shifter functions, A/D converters, audio and RTC.
Bluetooth and FM radio are physically integrated in one single ASIC.
Key components
Function Description Item ref
Main board 2MJK/2MJL
Energy management ASIC PEARL_J N2200
RF ASIC Vapaus N7500
Processor RAP3GS2v4 D2800
PA GSM Front end module (FEM), quad band N7520
PA WCDMA Triple band PA N7540
Oscillators VCTCXO G7500
Memory 1 Gbit M3/ DDR SDRAM 512 Mbit combo (stacked with RAP) D3000
FM radio BTHFMRDS3.0 module N6000
Bluetooth BTHFMRDS3.0 module N6000
Slide switch Hall IC switch/position sensor N2460
Battery BL-5C
Battery connector Lynx interface X2080
MicroUSB connector For data and charging X2002
MicroSD connector X3200
SIM connector X2700
Microphone B2104
IHF speaker B2121
Earpiece B1000
Vibra M2100
Camera
USB transceiver N2002
RM-721; RM-722
System Module
Issue 1 COMPANY CONFIDENTIAL Page 5 – 5
Copyright © 2011 Nokia. All rights reserved.
