Using the WristOx2, Model 3150
2. Place the device on the back of the patient’s arm and wrap the strap around the
patient’s arm.
3. Thread the rounded end of the strap through the strap bar by the sensor port (figure 18).
S
tart from the back of the device and pull it towards the front of the device.
Figure 18: Thread Single Strap
4. Pull the strap through the strap bar until the device fits comfortably on the patient’s
wrist (figure
19).
Figure 19: Tighten Single Strap
