6 Operating status messages
BU 0240 en-US-4920 83
Pos: 672 /A nleit ung en/El ek tr onik /FU und Star ter /6. M eldung en zum B etrie bsz ust and /Stör m eld ung en (A ufli st ung)/ Fehl er E0 11 [ SK 180E ... SK 5xxE/S K 500P/SK 3 00P] @ 43\mod_1592386576774_14638.docx @ 2634691 @ @ 1
E011
11.0
Control terminals
A/D inverter error
Internal customer unit (internal data bus) faulty or damaged
by radio radiation (EMC)
• Check control connections for short circuit.
• Minimize EMC interference by laying control and power
cables separately.
• Device and shielding must be well grounded.
Pos: 673 /A nleit ung en/El ek tr onik /FU und Star ter /6. M eldung en zum B etrie bsz ust and /Stör m eld ung en (A ufli st ung)/ Fehl er E0 12 [ SK 1 80E/ SK 2xx E/S K2x xE-FD S/SK 5 00P] @ 2\mod_1347454267926_14638.docx @ 46727 @ @ 1
E012 12.0 External watchdog The Watchdog function is selected at a digital input and the
impulse at the corresponding digital input is not present for
longer than the time set in parameter P460 >Watchdog
time<.
• Check connections
• Check setting P460
12.1 Limit moto./Customer
"Motor switch-off limit"
The drive switch-off limit (P534 [-01]) has triggered.
• Reduce load on motor
• Set higher value in (P534 [-01]).
12.2 Limit gen.
"Generator switch-off limit"
The generator switch-off limit (P534 [-02]) has triggered.
• Reduce load on motor
• Set higher value in (P534 [-02]).
12.3 Torque limit Limit from potentiometer or setpoint source has switched off.
P400 = 12
12.4 Current limit Limit from potentiometer or setpoint source has switched off.
P400 = 14
12.5 Load monitor Switch-off due to overshooting or undershooting of
permissible load torques ((P525) … (P529)) for the time set
in (P528).
• Adjust load
• Change limit values ((P525) ... (P527))
• Increase delay time (P528)
• Change monitoring mode (P529)
12.8 AI minimum,
“Analog In minimum”
Switch-off due to undershooting of the 0% adjustment value
(P402) with setting (P401) "0-10 V with switch-off on error 1"
or "....2"
12.9 AI maximum,
“Analog In maximum”
Switch-off due to overshooting of the 100% adjustment
value (P402) with setting (P401) "0-10 V with switch-off on
error 1" or "....2"
