Nord Drivesystems NORDAC FLEX SK 215E Series Brief Instructions

NORDAC FLEX (SK 200E ... SK 235E) – Brief instructions for Frequency Inverters
84 BU 0240 en-US-4920
Pos: 675 /A nleit ung en/El ek tr onik /FU und Star ter /6. M eldung en zum B etrie bsz ust and /Stör m eld ung en (A ufli st ung)/ Fehl er E0 13 [ SK 2 00E ... SK 5xxE] @ 2\mod_1347454271218_14638.docx @ 46752 @ @ 1
E013 13.0 Encoder error No signal from encoder
• Check 5 V sensor if available
• Check supply voltage of encoder
13.1 Speed slip error
"Speed slip error"
The slip speed error limit was reached.
• Increase value in P327
13.2 Disconnect. control,
“Shut-down monitoring”
The slip error monitoring was triggered; the motor could not
follow the setpoint.
• Check motor data P201-P209! (important for current
controllers)
• Check motor circuit
• Check encoder settings P300 and following in servo
mode
• Increase value for torque limit in P112
• Increase value for current limit in P536
• Check deceleration time P103 and extend if
necessary
13.5 Reserved Error message for POSICON  see supplementary manual
13.6 Reserved Error message for POSICON  see supplementary manual
Pos: 676 /A nleit ung en/El ek tr onik /FU und Star ter /6. M eldung en zum B etrie bsz ust and /Stör m eld ung en (A ufli st ung)/ Fehl er E0 14 "r es erviert" [SK 200E ... S K 5xxE/SK 50 0P] @ 2\mod_1347454273854_14638.docx @ 46777 @ @ 1
E014 --- Reserved Error message for POSICON  see supplementary manual
Pos: 677 /A nleit ung en/El ek tr onik /FU und Star ter /6. M eldung en zum B etrie bsz ust and /Stör m eld ung en (A ufli st ung)/ Fehl er E0 15 [ SK 1 80E ... SK 5xxE] @ 2\mod_1347454278051_14638.docx @ 46802 @ @ 1
E015 --- Reserved
Pos: 678 /A nleit ung en/El ek tr onik /FU und Star ter /6. M eldung en zum B etrie bsz ust and /Stör m eld ung en (A ufli st ung)/ Fehl er E0 16 [ SK 1 35E ... SK 5xxE, SK xxxE-FDS] @ 2\m od_1347454280625_14638.docx @ 46827 @ @ 1
E016 16.0 Motor phase error A motor phase is not connected.
• Check P539
• Check motor connection
16.1 Magn. Current Watch
"Magnetizing current
monitoring"
Required exciting current not achieved at moment of switch-
on.
• Check P539
• Check motor connection
Pos: 679 /A nleit ung en/El ek tr onik /FU und Star ter /6. M eldung en zum B etrie bsz ust and /Stör m eld ung en (A ufli st ung)/ Fehl er E0 18 "r es ervier t" [ SK 2xxE/ SK 5 xxE /SK 2xxE- FDS, SK 500P] @ 44\mod_1594726433780_14638.docx @ 2645278 @ @ 1
E018
18.0
Reserved
Error message for “Safe Pulse Block”, see supplementary
instructions
Pos: 680 /A nleit ung en/El ek tr onik /FU und Star ter /6. M eldung en zum B etrie bsz ust and /Stör m eld ung en (A ufli st ung)/ Fehl er E0 19 [ SK 1 80E/SK 2xxE/SK 5xxE/SK2xxE-FD S, auß er SK 500 P] @ 2\mod_1347454285788_14638.docx @ 46877 @ @ 1
E019 19.0 parameter ident.
"Parameter identification"
Automatic identification of the connected motor was
unsuccessful
• Check motor connection
• Check preset motor data (P201 … P209)
• PMSM – CFC Closed Loop Operation: Rotor position
of motor incorrect in relation to incremental encoder
Determine rotor position (initial enable after a "Power
On" only with motor stationary) (P330)
19.1 Star/delta incorrect
"Motor star/delta circuit
incorrect"
