Nordmann AT4 - Identification of the Unit

9
3.2 Identicationoftheunit
The identication of the unit is found on the type plate:
Walter Meier (Climate International) Ltd. 3562 Pfäfkon
Type: AT4 4564 Ser.Nr.: XXXXXXX 02.10
Heating voltage: 400V / 3~ / 50...60Hz Power: 33.8 kW
Steam capacity: 45.0 kg/h Ctrl. Voltage: 230V / 1~ / 50...60Hz
Water pressure: 1...10 bar
Made in Switzerland
Type designation Serial number (7 digits) Month/Year
Heating voltage
Maximum steam capacity per unit
Admissible water supply pressure
Power consumption
Control voltage
Field with certication symbols
Module A
Module B
