• miscellaneous optional/custom equipment
• dc power plant
• dc power distribution facility
• cooling facilities including fan shelves and temperature alarm sensors
For an illustration of the frame/bay layout, see Figure 2-6 and Figure 2-7.
Figure 2-6
Frame/bay layout (front view)
AN0048.eps
Frame/bay A Frame/bay C Frame/bay B
SPC compartment
Battery string
AC compartment 1
Front view of cabinet
4 3 2
