Installation guidelines
3-9
User Guide Rel 1.0 Standard May 1999
Figure 3-2
Cabinet mounting template
AN0005.tif
37.750
88.50
0
46
.50
2.7
5
1
1
2
.5
0
TORQUE P34617 AND P71313 TO
75 FT-LBS (4 PLACES)
1
2
3
4
Note:
All dimensions are in inches.
No. Qty. Description
1 1 Pad template, weldment
2 4 Bolt, 1/2-13x1 HH
3 4 Washer,1/2” plain
4 4 Nut, wing
