Procedure 3-9 (continued)
Connecting the earth ground to the cabinet
Table 3-2 lists the minimum torque for bonding and ground connections using
different nut sizes.
Table 3-2
Minimum torque for bonding and ground connections
Nut size Torque (in-lb) Torque (ft-lb) Torque (n-m)
6-32 7.5 0.6 0.9
8-32 9.0 0.8 1.0
10-32 12 1.0 1.4
12-24 16 1.3 1.8
1/4 in-20 32 2.7 3.6
5/16 in-20 60 5.0 6.8
