 9RLFH $ODUP 6\VWHP Installing Audio Amplifiers (AA-30/AA-100/AA-120)
4-10 AFP-300/AFP-400 Installation PN 50253:C1 05/22/97
,QVWDOOLQJ$XGLR$PSOLILHUV$$$$$$
,QVWDOOLQ
J
DQ$$
2YHUYLHZ
The AA-30 mounts in a CHS-4L chassis, which can hold two AA-30s placed side by
side. In addition to mounting, do the following:
1. Connect a primary (AC) and a secondary (24 VDC battery) power source to each
AA-30.
2. Provide an external device (such as an MPS-400) for charging the batteries.
0RXQWLQJ DQ $$
Mount an AA-30 into a CHS-4L chassis by following these steps.
)LJXUH  0RXQWLQJ DQ $$ LQWR D &+6/ &KDVVLV
Step Action
1 Put the bottom end of the
AA-30 assembly into
the slot in the bottom of
the CHS-4L chassis.
Swing the assembly into
the chassis.
2 Secure the AA-30 to the
chassis with the washers
and retaining nuts.
&+6/
$$
:DVKH U DQG UHWDLQ LQJ
QXW  SODFHV
